iLink - Configuration and Support Utility 25
iquest@iquest.co.nz
If you have selected a dial-up connection you will now be asked to complete two additional steps:
Specifying the modem
Specifying the telephone number
If you have selected a radio or direct connection, these steps will not apply.
Select the modem that you will be using for the dial-up connection.
There are a large number of modem types to choose from. Information about modem types available and
their configuration strings is available in Appendix B. If specific information about a modem is required,
use an editor such as NotePad or WordPad to view the Modems.ini file that is in the root directory of iLink.
Alternatively use the standard windows modem from the list.
Enter the telephone number of the device to which you are connecting. Include any prefix numbers
required to access an outside line etc. A comma introduces a 1 second delay in the dialing string.
Continue on following page for all connection types:
