Quick Guide Owner manual

Conﬁguration

Next step is to conﬁgure the Connect

based on the shown signal list. In the

function menu, choose Pump Control 1 and setup the speciﬁc menu items as

described in the signal list.

Go to Functions Menu and choose Pump Control 1, which contains the fol-

lowing items:

• Number of Pumps: Number of pumps in the wasterwater pump station.

• Measurement: The analog input on which the level transmitter is mounted

on and scaling and signal name.

• Pumps Setup

• Start/Stop levels: start and stop levels for current number of pumps.

• Control Word: 16-bit control word for intelligent pump controlling.

• Additional Functions with:

• Flow calculation

• Setpoint displacement

• Depth pumping

• Create Overview Screen: Connect will setup the screen 1 with the entered

information on overview screen 1.
