Quick Guide Owner manual

11
The list shows signals connected to the digital inputs in this example.
Digital
Input
Signal Name Relay
Function
Delay Alarm /
In use
Alternation
DI 1 Operation P1 NO 0 sec. In use In use
DI 2 Operation P2 NO 5 sec. In use In use
DI 3
DI 4 Thermo alarm P1 NO 15 sec. Alarm
DI 5 Thermo alarm P2 NO 15 sec. Alarm
DI 6
DI 7 Klixon P1 NO 0 sec. Alarm
DI 8 Klixon P1 NO 0 sec. Alarm
DI 9
DI 10 MAN-0-AUT P1 NO Alarm
DI 11 MAN-0-AUT P1 NO Alarm
DI 12
DI 13
DI 14
DI 15
DI 16 High Level
Switch
NO Alarm
The list shows the signals connected to the digital outputs in the example.
Digital
output
Signal Name Relay Function Close time
(seconds on time)
Delay
DO 1 Start/Stop P1 NO-constant 0 sec. 0 sec.
DO 2 Start/Stop P2 NO-constant 0 sec. 0 sec.
DO 3
DO 4
DO 5
DO 6
DO 7
DO 8 Joint reset of
thermo error
NO-time controlled 1 sec. 0 sec.
