Device Configuration
The XT6350 is a full-feature device based on a platform that allows rapid customization by market and
application requirements. The XT6350 series offers highly configurable firmware which allows full control of
device reporting behavior. The customizable messages provides only the data required to support unique
and evolving business needs. The XT6350 configuration is accomplished by loading 2 files:
Script File
Parameter File
The Script File is the file that triggers the alerts and actions of the XT6350.
The Parameter File specifies values used to configure hardware peripherals, network behavior, and inputs
to core functionality of the XT6350.
Script File
A Script file can contain an unlimited number of Triggers. When scripting the Triggers are group
into individual Trigger blocks. A trigger block is comprised of the following sections:
Trigger
Conditional Actions - optional
Actions
EXAMPLE:
trigger when Eq(InputState(0), 1) [Debounce(0, 0)]
condact always
actions
run BuildAndSendMsg(0, 2, 0, 0)
DESCRIPTION:
When ignition goes high a message is sent to the server.
Important notes on Scripting:
Park Time
X
Virtual Odometer
X
Quick Fence
X
Device Diagnostics
X
Motion
X
Accelerometer
X
Geo-Zones
50 Circular
Back Up Battery
250mAh
Communication Protocol
TCP, UDP , UDPwACK
Firmware Download
FTP
