Getting Started
2.13
2
Using a Parallel Cable
N
OTE
: Connecting the machine to the parallel port of the
computer requires a certified parallel cable. You need to buy an
IEEE-1284 compliant parallel cable that is 3 m or less in length.
1
Make sure that both the machine and the computer are
turned off.
2
Connect the parallel cable to the parallel connector on your
machine.
Push the metal clips down to fit inside the notches on the
cable plug.
3
Connect the other end of the cable to the parallel interface
port on your computer, and tighten the screws.
