Specifications
E.2
General Specifications
Item Description
Automatic document
feeder
Up to 50 sheets (20 lb, 75 g/m
2
)
ADF document size
Width: 142 to 216 mm (5.6 to 8.5 inches)
Length: 148 to 356 mm (5.8 to 14 inches)
Paper input capacity
Paper tray (standard Tray 1 and optional Tray 2): 250
sheets (weight: 75 g/m
2
, 20 lb)
Bypass tray: 50 sheets for plain paper (weight: 75 g/m
2
,
20 lb), 5 sheets for card stock, labels, transparencies,
and envelopes
Paper output capacity
Front output tray: 150 sheets (face down)
Rear output slot: 1 sheet (face up)
Paper type
Paper tray: Plain paper (60 ~ 90 g/m
2
, 16 ~ 24 lb)
Bypass tray: Plain paper, Transparencies, Labels, Card,
Post card, Envelopes (60 ~ 120 g/m
2
, 16 ~ 32 lb)
Consumables 1-piece toner cartridge system
Power requirements
100 ~ 127 VAC, 50/60 Hz, 5.0 A
220 ~ 240 VAC, 50/60 Hz, 2.6 A
Power consumption
Sleep mode: 30 W
Average: 400 W
Noise
*
Standby mode: Less than 39 dBA
Printing: Less than 54 dBA
Copy: Less than 55 dBA
Warm-up time
Less than 42 seconds
Operating conditions
Temperature: 50
o
F to 89
o
F (10
o
C to 32
o
C)
Humidity: 20 % to 80 % RH
LCD
16 characters x 2 lines
Toner cartridge life
**
3,500 or 5,000 pages at ISO 19752 5 % coverage (Ships
with 3,500 pages Start Toner Cartridge)
SET dimension
(W x D x H)
450 x 435 x 457 mm
Weight
Net: 17 Kg (including consumables)
Gross: 21 Kg (including consumables, accessories and
package)
