Basic Troubleshooting
WorkCentre Pro 555, 575 4-1
4 Basic Troubleshooting
Paper Jam
If a paper jam occurs during a reception or copying operation, the
message “PAPER JAM XX” is displayed. If this occurs, follow the
procedure below.
The code number "XX" indicates the location of the paper jam as
shown in the table below.
If a paper jam occurs during a reception, the received documents are
automatically stored in memory. Once the paper jam is corrected, the
machine automatically prints the contents that were in memory.
See Chapter 3, “Loading Documents” for document specifications
and recommendations which can help avoid paper jams.
Code Location
10 In the Paper Tray or Bypass Tray
20 In the Optional Paper Tray
80 At the paper feed area
90 At the paper exit area
Note: The power can be left ON when clearing a paper jam.
