Setting the Send Header
With this feature enabled, your Send Header information is printed at
the top of each page you send. When enabling the Send Header
feature, you can specify where the header is to be printed “inside” or
“outside” the document data area. If “Inside” is selected and sending
data exists near the top edge of the paper, the header information
and data may overlap. If “Outside” is selected, the header information
is printed at the top of the page and the document is printed below to
avoid overlapping.
The following information is printed on the Send Header:
• Date
• Start Time
• Transmitting Station ID (department, name & telephone number)
• Transmission Serial Number - The machine automatically
assigns a three digit number. This number is used on
confirmation reports or error reports.
• Page Number/Total Number of Pages
• Job or File Number
To enable the Send Header:
1. Press:
Menu
3.Off
2.Outside
Send header
1.Inside
