Introduction
WorkCentre Pro 555, 575 2-11
18 Used to create a one time group of phone
numbers, for Group Sending or Polling. Speed
dial and one touch numbers can be used.
19 Used to copy documents.
20
Used for interactive dialing. Digits are dialed as
the key is pressed. The line monitor
automatically turns on.
21 Used to set the copy reduction. The following
settings are available:
100%, Auto Fit, 86%, 75%, 50%
22 Used to set the resolution for copying,
scanning, or faxing. The following settings are
available: Standard (no LED lit, fax only), Fine,
Superfine, Photo.
23 Sets the contrast of the printout to Normal (no
LED lit), Lighten, or Darken. This is a scanner
setting affecting send and copy.
24 Deletes pending and active jobs. You must
select the appropriate job type to display the
desired job for cancellation. Once the job is
displayed, pressing Cancel Job again displays
the Cancel Job Confirmation screen.
When used in conjunction with the Job Status
key, active jobs can be canceled quickly by
pressing this key then confirming the
cancellation.
25 This feature turns power off to minimize power
consumption, if the machine has not been used
for a period of time.
Item Description Function
Manual
Group
Copy
Manual
Dial
Reduce Copies
Resolution
Contrast
Cancel
Job
Power Save
