Printer User Manual

Additional Memory
Chapter 6: Installing Printer Options ❖ 6-53
4
Remove the two screws that secure the controller board’s
access cover.
5
Remove the access cover by (1) pulling it out at the
bottom, (2) lifting it up slightly, then (3) pulling it away at
the top.
6
To install the memory, insert it into an available slot and
gently push it in until the edge clips lock into place.
If the clips do not automatically engage, you
should manually close them.
7
To remove memory, pull out the edge clips to free it and
gently pull it out of the slot.
2
1
3
