Interface Card
Chapter 6: Installing Printer Options ❖ 6-49
5
Remove the access cover by (1) pulling it out at the
bottom, (2) lifting it up slightly, then (3) pulling it away at
the top.
6
Remove the two screws that secure the card to the
controller board. Set the screws aside to use later in this
procedure.
7
Remove the card by gently lifting it away from the
receptacle and pulling it away from the controller board.
8
Use the screws from Step 6 to attach the interface cover
plate that came with the printer.
2
1
3
