User Manual

Xerox
®
VersaLink
®
B405 Multifunction Printer
Page 2 of 10
DEVICE SPECIFICATIONS
ELECTRICAL REQUIREMENTS
North America
Voltage: 110-127 VAC
Frequency: 50/60 Hz 11 A
Europe and Other Geographies
Voltage: 220-240 VAC
Frequency: 50/60 Hz 6 A
POWER CONSUMPTION
Continuous Printing
4
620 watts or less
Ready (Standby) Mode
4
60 watts or less
Energy Saver (Sleep Mode)
4
4 watts or less
OPERATING ENVIRONMENT
Required Temperature Range
(Storage)
32 to 95° F / 0 to 35° C
Required Temperature Range
(Operating)
50 to 90° F / 10 to 32° C
Required Relative Humidity
10%to 85%
Sound Power Levels
Running
Standby
7.5 B(A) or less
5.3 B(A) or less
Sound Pressure Levels
Running
Standby
56 dB(A) or less
30 dB(A) or less
Boot Time
(from Off to UI Ready)
As fast as 60 seconds
Warm-up Time
(from Sleep to UI Ready)
As fast as 5 seconds
DIMENSIONS AND WEIGHT
(UNPACKAGED)
WIDTH
DEPTH
HEIGHT
WEIGHT
VersaLink B405
19.5 in. / 495 mm
19.5 in. / 495 mm
21.7 in. / 551 mm
48 lb. / 22 kg
550-sheet Paper Tray
17 in. / 432 mm
18.3 in. / 465 mm
3.7 in. / 94 mm
7.7 lb. / 3.5 kg
DIMENSIONS AND WEIGHT
(PACKAGED)
WIDTH
DEPTH
HEIGHT
WEIGHT
VersaLink B405
24.3 in. / 618 mm
24.6 in. / 626 mm
28.1 in. / 713 mm
59.7 lb. / 27.1 kg
550-sheet Paper Tray
21.1 in. / 535 mm
29.7 in. / 754 mm
9.2 in. / 234 mm
11.5 lb. / 5 kg
SYSTEM CERTIFICATION / REGULATORY COMPLIANCE
Certifications
To view the latest list of certifications, go to www.xerox.com/OfficeCertifications.
