Automatic Document Feeder
Automatic Document Feeder Guidelines
The Automatic Document Feeder accommodates the following original-sized documents:
• Width: 5.8–8.5 in. (148–216 mm)
• Length: 5.8–14 in. (148–356 mm)
• Weight: 16 - 28 lb (60–105 g/m
2
)
Follow these guidelines when loading original documents into the automatic document feeder:
• Load original documents face up so that the top of the document enters the feeder first.
• Place only loose sheets of undamaged paper in the automatic document feeder.
• Adjust the paper guides so that they fit against the original documents.
• Insert paper in the automatic document feeder only when ink on the paper is dry.
• Do not load original documents above the MAX fill line.
13 Automatic Document Feeder 15 Document Glass
14 Constant Velocity Transport (CVT) Glass 16 Automatic Document Feeder Guides
15
13
14
16
