3.2 Communication Parameter Setup (Printer Control Panel, 6030/6050)
3.2
Communication Parameter Setup
(Printer Control Panel, 6030/6050)
This section explains the procedures for setting up the communication
parameters from the printer control panel.
Procedure
1 Press the < > key with [PORT SETTING]
displayed.
2 Select the interface that is to be set up with
the use of the <
> and < > keys, and
then press the < > key.
[TCP/IP], [SERIAL], [CENTRO], and [VPI]
will be displayed, in that order.
3 Select the parameters with the use of the
<
> and < > keys, and then press the
<Set> key.
An asterisk [*] will be displayed on the right
side of the value once it has been set up.
4 After setting up all of the parameters, switch
the printer power off and then on for the
changes to take effect.
TCP/IP Setup
SNMP must be set up from Print Services on Web.
The changed parameters become valid after the machine is rebooted.
[CENTRO] and [VPI] are optional.
The changed parameters are saved
to the system when the <Set> key is
pressed. It is not necessary to save
each change individually.
Refer to the previous section for
detailed information about each of
the communication parameters.
MENU
PORT SETTING
PORT SETTING
TCP/IP
TCP/IP
Ethernet Setting
Ethernet Setting
AUTO *
