68
Chapter 3 Printer Setup
SNMP (6030/6050 Only)
The communication parameters listed below must be set up.
SNMP must be set up in Print Services on Web.
The communication parameter nomenclature on the printer control panel will
sometimes differ from the nomenclature on Print Services on Web. The Print
Service on Web nomenclature appears in bold type in the table below.
Menu Item Description
SNMP Sets whether or not to enable SNMP.
Community
String
Sets the community String to be imbedded when the
client transmits SNMP packets.
Trap address Sets the IP address of the destinations (trap transmission
destinations) to which notifications are to be sent in the
event of an error occurring with the printer.
A maximum of 128 trap transmission destinations can be
saved.
Transmission Port
(Send port)
Sets the port numbers of the trap transmission
destinations.
Version Sets the version of the trap to be transmitted.
Permanence
(Persistence)
Sets whether the trap transmission destination
information is to be stored or not after the printer has
been switched off. A maximum of eight items can be
enabled for permanence.
