67
3.1 Communication Parameters
VPI (optional, 6030/6050 Only)
The following VPI communication parameters must be set up.
Menu Item Description
REPORT
OFFLINE
Determines if the host will be notified offline of the media
running out.
The default setting is [NO].
[YES] Issues offline notification.
[NO] Does not issue offline notification.
EOP Timeout Determines if the EOP Timeout will be enabled [TIMEOUT]
or disabled [NO_TIMEOUT]. If set to [TIMEOUT], a
Timeout Value must be entered. The timeout value is
entered within a range of 1 to 255* seconds.
The default setting is [10 sec].
Job Separation Sets the job separation. The default setting is [NO].
[YES] Starts conversion processing once the
command that recognizes the end of the data is
received, even if this occurs midway through
the file.
[NO] Performs the spooling process on the hard disk
until a timeout is issued.
*If a value higher than [255] is entered for the timeout value, [255] will be set
as the value.
