66
Chapter 3 Printer Setup
Centronics (optional, 6030/6050 Only)
The Centronics communication parameters are presented below.
Menu Item Description
Ack Mode The Ack mode is selected from [MODE0], [MODE1],
[MODE2], [MODE3], and [MODE7].
The default setting is [MODE0].
DMA Timeout The timeout value for data input is entered within a range
of 1 to 255 seconds. The default setting is [5 sec].
EOP Timeout Determines if the EOP Timeout will be enabled [TIMEOUT]
or disabled [NO_TIMEOUT]. If set to [TIMEOUT], a
Timeout Value must be entered. The timeout value is
entered within a range of 0 to 99 seconds.
The default setting is [10 sec].
Job Separation Sets the job separation. The default setting is [NO].
[YES] Starts conversion processing once the
command that recognizes the end of the
data is received, even if this occurs midway
through the file.
[NO] Performs the spooling process on the hard
disk until a timeout is issued.
• If a value higher than [255] is entered for the DMA Timeout value, [255] will
be set as the value.
• Changes to the [Ack Mode] and [DMA Timeout] values will have no effect on
operations.
