64
Chapter 3 Printer Setup
Serial (6030/6050 Only)
The serial communication parameters are listed below.
The communication parameter nomenclature on the printer control panel will
sometimes differ from the nomenclature on Print Services on Web. The Print
Service on Web nomenclature appears in bold type in the table below.
Menu Item Description
Default Parser The default setting is [HP-GL].
Logical printer
number
Sets up a logical printer number to be use if a logical
printer is not defined in the print job.
Handshake Selects the handshake method from the following choices.
The default setting is [XON/XOFF].
[XON/XOFF] Handshake using the XON/XOFF protocol.
[HARDWARE] Handshake using the hardware.
[ENQ-ACK] Handshake using the ENQ-ACK protocol
(HP-GL only).
[SOFTWARE] Handshake using the application program
(HP-GL only).
Baud Rate Sets the communication speed to [300], [1200], [2400],
[4800], [9600], or [19200].
The default setting is [9600].
Parity Sets the parity bit to [NONE], [EVEN], or [ODD].
The default setting is [EVEN].
Data Bit Sets the data bit length to [7_BITS] or [8_BITS].
The default setting is [7_BIT].
Stop Bit Sets the stop bit length to [1_BIT] or [2_BIT].
The default setting is [1_BIT].
EOP Timeout Determines whether or not to enable EOP timeout.
The default setting is [ON] or [Enable].
Timeout Value Sets up the EOP timeout value within a range of 1 to 255
seconds. If a value greater than 255 is entered, the timeout
value will be set to 255.
The default setting is [10].
Output
Response
Enables [YES] or disables [NO] the output response.
This must be set to [YES] if the printer requires a response
when data is transmitted from the host to the printer.
The default setting is [NO].
