61
3.1 Communication Parameters
TCP/IP
The following TCP/IP communication parameters must be set up for the
6030/6050.
The communication parameter nomenclature on the printer control panel will
sometimes differ from the nomenclature on Print Services on Web (6030/
6050) or Web Printer Management Tool (6050A). The Print Service on Web
and Web Printer Management Tool nomenclature appears in bold type in the
table below.
Menu Item Description
Default Parser Selects the parser or data format interpreter that
will be used when the input data format has not
been specified from among the available
selections, that is, [HPGL], [VERSATEC], [TIFF],
[CALS], or [PS/PDF]. The default setting is
[HPGL].
Ethernet Setting
(Physical Layer)
Selects the ethernet setting/physical layer. The
default setting is [AUTO].
[AUTO] Automatic recognition
[10BASE_T] Fixed at 10BASE_T
[100BASE_T] Fixed at 100BASE_T
IP Address The IP address of the machine in the format
XXX.XXX.XXX.XXX. The IP address can be
changed, if necessary.
MASK Value
(Net mask)
The sub-net mask set up on the machine in the
format XXX.XXX.XXX.XXX. The subnet mask can
be changed, if necessary.
E-Net Address
(Ethernet address)
Displays the Ethernet address. The value
displayed is unique for the hardware and cannot
be changed.
FTP Determines whether or not to enable FTP. The
default setting is [Enable].
Dynamic Routing Determines if dynamic routing will be enabled.
The default setting is [ON].
Static Routing* Determines if static routing will be enabled. The
default setting is [OFF]. Set Static Routing to [ON]
when you need to view the device through a
gateway or router.
