Chapter 3 Printer Setup
3.1 Communication Parameters
The 6030/6050/6050A Wide Format Printer and Copier/Printer must be
connected to a host PC before printing can be performed. Once the Printer or
Copier/Printer is connected to the network, the communication parameters must
be set up. The communication parameters can be set up from the printer control
panel or from Print Services on Web (6030/6050). This section explains how to
use both methods to perform the setup procedures. Explained, too, is the
procedure for printing a list of the communication parameters.
Communication Parameters Definitions
Communication parameters may be defined for the following.
(*6030/6050 Only)
• TCP/IP
• *Serial
• *Centronics (optional)
• *VPI (optional)
• *SNMP
SNMP can only be set up from Print Services on Web.
