Chapter 2 Printer Overview
Operation Examples
This section provides examples of how to select menu items.
1 Press the <Menu> key.
The machine will enter the offline mode.
2 Press the < > key.
The top selection in the [NETWORK/PORT
SET] menu will display.
3 Press the < > key.
The menu items will display in order.
4 Press the < > key.
The sub-menu items will display.
5 Press the < > key.
The menu items on the same level will
display in order.
6 Press the < > key.
The menu items on the next level will
display.
7 Press the < > key to return to the higher
level.
8 Press the < > key to return to an even
higher level.
The previous menu will display if the
<
> key is pressed.
Ready to print
MENU
NETWORK/PORT SET
<Menu> key
MENU
SYSTEM PARAMETER
<> key
MENU
PORT SETTING
<> key
PORT SETTING
TCP/IP
<> key
PORT SETTING
SERIAL
<><> key
SERIAL
Handshake
<> key
PORT SETTING
SERIAL
<> key
MENU
PORT SETTING
<> key
