Chapter 2 Printer Overview
Overview of the Operation Menu
The printer control panel’s operation menu is depicted in the image below.
Descriptions of the sub-menus follow.
SYSTEM PARAMETER MENU
Sets up the system management information, such as the system date and
power save mode settings.
Refer to "3.2 Communication Parameter Setup (Printer Control Panel, 6030/
6050)" for the 6030/6050 and "3.3 Communication Parameter Setup (Printer
Control Panel, 6050A)" for the 6050A for setup procedures.
< > button
< > button
Return to higher level
Move to lower level
Return to the previous
Return to higher level
Online Mode
<Menu> button
Offline Mode
Specified values:
Select with the < >
and < > buttons,
and set with the <Set>
button.
< > button
< > button
Operation menu
MENU
NETWORK/PORT SET
MENU
PRINT SETUP
MENU
SYSTEM PARAMETER
MENU
PORT SETTING
MENU
TEST PLOT
MENU
JOB LOGGING
MENU
OFFLINE PLOT
MENU
BILLING INFO
SYSTEM PARAMETER
Set Date
SYSTEM PARAMETER
AUTO ROLL
SYSTEM PARAMETER
SPA PAPER WIDTH
Ready to print
SPA PAPER WIDTH
Sp A1
SPA PAPER WIDTH
Sp A2
