43
2.1 Overview of the 6030/6050/6050A Wide Format Printer
Canceling Jobs
Jobs transmitted to the 6030/6050/6050A Wide Format can be deleted by
pressing the <Cancel Job> key on the printer control panel. It is also possible to
cancel jobs from Print Services on Web.
Meter Display
The billing meters can be checked from both Print Services on Web (6030/6050
only) and the printer control panel.
Job Recovery
This machine is equipped with a recovery function for media jams and when
media runs out.
• Media Jams
Documents that failed to print because of a media jam will print when the jam is
cleared.
• No Media
Printing of a print job that is stored in memory will restart when the media is
loaded in the printer.
The printer also can be set up to print (or not print) jobs that remained in the print
queue when the printer was switched off.
Refer to "2.2 Printer Control Panel Usage" for details on the <Cancel Job>
key, and "4.5 Print Services on Web: Job and Log" for details on Print Service
on Web operations.
Refer to "4.6 Print Services on Web: Status" for details on web operations,
and "5.7 Billing Meter Confirmation (6030/6050)" for the 6030/6050 and "5.8
Billing Meter Confirmation (6050A)" for the 6050A for details on printer control
panel operations.
Refer to "3.2 Communication Parameter Setup (Printer Control Panel, 6030/
6050)" for the 6030/6050 and "3.3 Communication Parameter Setup (Printer
Control Panel, 6050A)" for the 6050A, and also to the topic "Setting Up [Job
Recovery]" in "3.8 System Parameter Setup (Print Services on Web, 6030/
6050)" for details on job processing after the power is switched on.
