16
1.7
Logical Printers Overview (6030/6050)
A logical printer (virtual printer) is a group of saved print job settings for a
particular data format, i.e., HP-GL, Versatec, TIFF, CALS, and PS/PDF. These
saved settings, which are created using Print Services on Web, may include pen
attributes, media type, print quantity, and the other parameters that define the
print job that the logical printer will be required to perform. Logical printers are to
printing as Stored Jobs are to copying, that is, both reduce setup time and
increase efficiency by using previously saved job settings. A maximum of one
hundred logical printers can be set up within one 6030/6050 Wide Format
Printer or Copier/Printer for each supported data format.
How Logical Printers are Named
Logical printer names are assigned based on the following. This naming
structure can not be changed.
1st to 3rd digits [PLT] or [plt] character strings
4th to 5th digits (number) Two-digit number from 00 to 99
6th digit (data format) Any of the following.
H: HP-GL format
V: Versatec format
T: TIFF format
C: CALS format
A: PS/PDF format (optional)
Refer to "Chapter 4 Logical Printer Setup and Operation (6030/6050 only)" to
learn how to set up logical printers.
P L T 0 0 H
Number
Format
