12
1.5
Printer Control Panel Overview
Both the Printer and the Copier/Printer versions of the 6030/6050/6050A Wide
Format are equipped with a printer control panel. This section provides an
overview of this device.
Refer to section "2.2 Printer Control Panel Usage" and Chapter 5 for detailed
explanations of the use of the printer control panel.
It is seldom necessary to use the printer control panel on the 6030/6050
Wide Format Copier/Printer because the same settings usually can be
made using either the copier control panel or Print Services on Web, the
built-in web interface.
Used for setting up the
various functions. Displays
various messages.
[Online] lamp (green)
[Processing] lamp (green)
Printer display
Indicates the data
processing status.
ON Ready to print.
Blinking Moving to the
offline mode.
OFF The offline mode.
Printing is not
possible.
[Error] lamp (red)
Indicates a printing error.
ON Indicates that an error,
such as paper jamming,
has occurred.
OFF Printer operating
normally.
<Manual Feed Mode> button
Alternates between the online
mode and offline mode.
<Menu> button
Temporarily suspends a job
during printing.
<Pause> button
Sets the values specified on
the menu screen.
<Set> button
Cancels a job during printing.
<Cancel Job> button
Activates the energy-saving mode.
Also cancels the energy-saving mode.
ON Energy-saving mode
activated.
OFF Energy-saving mode
deactivated.
<Power Saver> button
Displays the items and specified
values on the menu screen.
< > < > < > < > buttons
Indicates the printing status.
ON Printing in process
Blinking Receiving print data
OFF Not printing
Currently not supported.
(6030/6050 only)
