Appendix 4 TIFF Tag List (6030/6050)
Appendix 4
TIFF Tag List (6030/6050)
Tag ID
Tag Name
Revision 6030/6050
Wide
Format
Hex Dec 4.0 5.0 6.0
00FE 254 NewSubfileType - y y y*
Bit 0: Low Resolution Image - y y -
Bit 1: Multi-Page Image - y y y
Bit 2: Transparency Mask - y y -
00FF 255 SubfileType y n n y*
1: Full Resolution Image y n n y
2: Reduced-Resolution Image y n n -
3: Multi-Page Image y n n y
0100 256 ImageWidth y y y y
0101 257 ImageLength y y y y
0102 258 BitsPerSample y y y y
0103 259 Compression y y y y*
1: uncompressed y y y y
2: CCITT 1D (MH) y y y y
3: CCITT T4 (MR) y y y y
4: CCITT T6 (MMR) y y y y
5: LZW - y y -
6: JPEG - - y -
32771: uncompressed y n n y
32773: PackBits y y y y
0106 262 PhotometicInterpretation y y y y*
0: WhiteIsZero y y y y
1: BlackIsZero y y y y
2: RGB y y y -
3: RGB Palette - y y -
4: Transparency Mask - - y -
5: CMYK - - y -
6: YCbCr - - y -
