11
Appendix 3 HP-RTL Command List (6030/6050)
Set Blue Parameter ESC * v # c|C
Defines the blue color configuration of
the color palette.
Only
concatenation
command valid
Assign Color Index
Number
ESC * v # i|I
Assigns a defined RGB parameter to
an index number.
Index Number
Push/Pop Palette ESC * p # P
Saves and restores palette
information.
Ignored
Start Raster
Graphics
ESC * r # a|A
Sets the controller to the raster mode
and sets the start position and left
margin of a graphic image.
End Raster Graphics ESC * r C
Indicates the end of raster graphic
image transfer.
Transfer Raster Data
by Plane
ESC * b # V[data]
Transfer's the data of a specified byte.
However, the CAP does not move to
the next raster position.
The plane pointer is updated but the
row pointer is not.
Data skipped
Transfer Raster Data
by Row/Block
ESC * b #
W[data]
Transfer's the data of a specified byte
as a line or as a block by the current
compression method.
Set Compression
Method
ESC * b # m|M
Determines the compression method.
Source Raster Width ESC * r # s|S
Indicates the image width of
succeeding raster data.
Source Raster
Height
ESC * r # t|T
Indicates the source raster image
height of succeeding raster data.
Move CAP
Horizontal
(Decipoint)
ESC & a # h|H
Moves the CAP horizontally by a
specified decipoint (1/720 inch).
Move CAP
Horizontal
ESC * p # x|X
Moves the CAP horizontally by a
specified value in Versatec resolution
inch units.
Move CAP Vertical ESC * p # y|Y
Moves the CAP vertically by a
specified value in Versatec resolution
inch units.
Y Offset ESC * b # y|Y
Moves the CAP vertically by specified
pixel rows.
Command name Command Command Meaning and function Limit
