Appendixes
Appendix 3 HP-RTL Command List (6030/
6050)
Command name Command Command Meaning and function Limit
Enter HPGL/2 Mode ESC % # B
Starts processing the following data
as an HP-GL2 command.
Transfer color
palette ignored
Enter PCL Mode ESC % # A
Starts processing the following data
as an HP-RTL command.
Transfer color
palette ignored
Reset ESC E
1. Outputs the data received so far.
2. Executes the HP-GL2 IN
command.
3. Returns HP-RTL CAP to (0,0).
4. Sets the controller to the HP RTL
parsing mode.
5. Terminates the raster mode.
Parameters not
changed
Universal Exit
Language/Start of
PCL
ESC % #x|X
1. Outputs all data input before this
command.
2. Returns the controller to the HP-
GL2 or HP
RTL parsing mode.
Apple Talk Config ESC & B #
W[binary data]
Sets communication with the Apple
Talk driver.
Not supported
Configure Image
Data
ESC * v #
W[data]
Sets up the controller as a color
controller as follows.
1. Determine each index bit and
creates a color palette.
2. Set a color model.
3. Set the pixel encoding mode.
4. Determines each RGB bit.
5. Sets a white/black value
corresponding to RGB.
Other
commands
ignored,
excluding the
pixel encoding
command
Set Red Parameter ESC * v # a|A
Defines the red color configuration of
the color palette.
Only
concatenation
command valid
Set Green Parameter ESC * v # b|B
Defines the green color configuration
of the color palette.
Only
concatenation
command valid
