9
Appendix 2 HP-GL/HP-GL2 Command List (6030/6050)
SS Specifies a font specified by the SD command. y y y
ST Sets the plot quality. y n
SV Selects a pattern type for vector and area filling. y n
TD Specifies whether to execute the functions of
control characters or to print the control
characters at label drawing.
y y
TL Specifies transparency or opaque when white
areas are overlaid.
y y
TR Specifies the length of ticks drawn on the
coordinate axis.
y y
UC Draws a user-defined character. y n
UF Draws a user-defined fill pattern. y y
UL Creates a specified line pattern. y y
VN Inactivates the VA command. n
VS Specifies the drawing speed. y n
WD Outputs a specified message to the panel. y n
WG Defines and fills in a sector polygon. y y y
WU Specifies whether to express the pen width in
millimeters or by percentage of the P1/P2
distance.
y y
XT Draws ticks on the X axis. y y
YT Draws ticks on the Y axis. y y
Com-
mand
Command Meaning and action HP-GL HP-GL/2
6030/6050
Wide Format
