Chapter 9 Specifications
Media Maximum width: 914 mm/36" (A0 size)
Minimum width: 210 mm/8.27" (A4 size)
Maximum length *:Plain media (A0/A1 width) 15 m/
650’,
A2/A3 width 6 m/19.68’
Vellum/Film: Twice standard size
Minimum length: 210 mm/8.27"
Dimensions Combination type 1,250 (W) × 640 (D) × 1,200 (H)
mm (excluding control panel)
Scanner 1,250 (W) × 625 (D) × 305 (H)
mm
(Including control panel)1,420 (W) × 625 (D) × 415 (H)
mm
Printer 1,250 (W) × 640 (D) × 940 (H)
mm
Weight Scanner 50 kg
Printer (2R type) 250 kg
Printer (4R type) 300 kg
Combination type (2R type) 300 kg
Maximum power
consumption
Scanner 260 W
Printer 3,200 W
Power consumption
when main power
switch is OFF
Main power switch OFF 0 W (printer)
Scanner power switch OFF 0 W (scanner)
Heat dissipation Maximum heat dissipation (printer)
Standby mode 1,800 kJ or less
Copy mode 9,000 kJ or less
Maximum heat dissipation (printer)
Standby mode 330 kJ or less
Copy mode 710 kJ or less
No power is consumed in the output section and printer when the circuit
breaker is OFF even if the power plug is connected to the power source.
Item Specification
