277
9.3 Media Specifications
9.3
Media Specifications
• For sharp image copying, use the media recommended by Xerox.
• To prevent media jams or uneven printing, do not use creased, wrinkled, or
curled media.
• When using unusually flexible media, support the media as it comes out of the
media ejection port so that it will not be pressed against the media table and
result in jams.
• Moisture is not good for media. Place the media in a storage bag and store it
in a relatively dry place.
Vellum media, especially, should be put in a plastic or moisture-proof bag
that contains desiccant.
• When the machine is not used for a long period, remove the media and store it
appropriately.
*1 Option
*2 A4 size can only be fed portrait.
Item Description
Media type/weight*
*Weight range = Light to
Heavy stock inclusive
Bond 16 to 29lb. (60 to 112gsm)
Vellum 18 to 29lb. (70 to 112gsm)
Tracing Paper 24 to 29lb. (90 to 112 gsm)
Film 50 to 100 microns (2 to 4 mil)
Size Roll Minimum width 297 mm, maximum
width 914 mm (standard size paper)
Manual loading
*1
Minimum width 210 mm, maximum
width 914 mm (standard size paper)
M.S.I.
*2
A3 (horizontal feed), A4 (portrait/
landscape feed)
Recommended
media
Bond (Roll) Premium and Performance Bond
(20lb./75gsm)
Bond (Cut sheet) Premium and Performance Bond
(20lb./75gsm)
Tracing Paper Premium Tracing
(24 to 29lb./90 to 112 gsm)
Vellum (Roll) HPH (18 to 29lb./70 to 112gsm)
Vellum (Cut sheet)HPH (18 to 29lb./70 to 112gsm)
Film (Roll) Premium Film (100 micron/4 mil)
Film (Cut sheet) Premium Film (100 micron/4 mil)
