274
Chapter 9 Specifications
Standard sizes and drawing areas
Series
Standard
size
Dimensions Drawing area (dots)
ISO A
series
A0 841 × 1,189 mm
(33.12 x 46.77")
19,872 × 28,064
A1 594 × 841 mm
(23.36 x 33.12")
14,016 × 19,872
A2 420 × 594 mm
(16.53 x 23.36")
9,920 × 14,016
A3 297 × 420 mm
(11.68 x 16.53")
7,008 × 9,920
A4 210 × 297 mm
(8.26 x 11.68")
4,960 × 7,008
SP. A
SP. A0 880 × 1,230 mm
(34.65 x 48.43")
20,768 × 29,056
SP. A1 625 × 880 mm (24.6 x 34.65")
620 × 871 mm (24.4 x 34.3")
14,752 × 20,768
14,624 x 20,576
SP. A2 440 × 625 mm (17.3 x 24.6")
435 × 620 mm (17.1 x 24.4")
10,400 × 14,752
10,272 x 14,624
SP. A3 312 × 440 mm (12.3 x 17.3")
310 × 435 mm (12.2 x 17.1")
7,360 x 10,400
7,328 x 10,272
ARCH
E 36 x 48 inches
(914.4 x 1219.2 mm)
21,600 × 28,800
D 24 x 36 inches
(609.6 x 914.4 mm)
14,400 x 21,600
C 18 x 24 inches
(457.2 x 609.6 mm)
10,800 × 14,400
B 12 x 18 inches
(304.8 x 457.2 mm)
7,200 × 10,800
A 9 x 12 inches
(228.6 x 304.8 mm)
5,400 × 7,200
