270
Chapter 9 Specifications
Print Length
• When the PS/PDF option is not in use
• When the PS/PDF option is in use
Paper Type Paper Width 512MB (Standard)
1024MB
(Extended)
Plain paper
A0 5,500mm 15,000mm
A1 7,500mm 15,000mm
A2 6,000mm 6,000mm
A3 6,000mm 6,000mm
36" 5,000mm 13,500mm
24" 6,900mm 15,000mm
18" 6,000mm 6,000mm
12" 6,000mm 6,000mm
Vellum/Film
A0 2,380mm 2,380mm
A1 1,680mm 1,680mm
A2 1,190mm 1,190mm
A3 840mm 840mm
Paper Type Paper Width 512MB (Standard)
1024MB
(Extended)
Plain paper
A0 3,500mm 12,000mm
A1 5,000mm 15,000mm
A2 6,000mm 6,000mm
A3 6,000mm 6,000mm
36" 3,000mm 11,500mm
24" 5,000mm 15,000mm
18" 6,000mm 6,000mm
12" 6,000mm 6,000mm
Vellum/Film
A0 2,380mm 2,380mm
A1 1,680mm 1,680mm
A2 1,190mm 1,190mm
A3 840mm 840mm
