9.1 Main Specifications (6030/6050)
ARCH
E 36 x 48 inches
(914.4 x 1219.2 mm)
21,600 × 28,800
D 24 x 36 inches
(609.6 x 914.4 mm)
14,400 x 21,600
C 18 x 24 inches
(457.2 x 609.6 mm)
10,800 × 14,400
B 12 x 18 inches
(304.8 x 457.2 mm)
7,200 × 10,800
A 9 x 12 inches
(228.6 x 304.8 mm)
5,400 × 7,200
ANSI
E 34 × 44 inches
(863.6 x 1117.6 mm)
20,400 x 26,400
D 22 × 34 inches
(558.8 x 863.6 mm)
13,200 x 20,400
C 17 × 22 inches
(431.8 x 558.8 mm)
10,200 x 13,200
B 11 × 17 inches
(279.4 x 421.8 mm)
6,600 x 10,200
A 8.5 × 11 inches
(215.9 x 279.4 mm)
5,100 x 6,600
E30 30 x 42 inches
(762 x 1,067 mm)
18,000 x 25,200
D 24 x 36 inches
(609 x 914.4 mm)
14,400 x 21,600
ARCH 30 C 18 x 24 inches
(457 x 609 mm)
10,800 x 14,400
B 12 x 18 inches
(304 x 457 mm)
7,200 x 10,800
A 9 x 12 inches
(228 x 304 mm)
5,400 x 7,200
Series
Standard
size
Dimensions Drawing area (dots)
