Chapter 9 Specifications
9.1
Main Specifications (6030/6050)
Supported data formats
• HP-GL formats: HP-GL, HP-GL2, and HP-RTL
• Versatec formats: Versatec Random Format (VRF), Versatec Color Graphic
Language (VCGL)
• TIFF formats: Conforming to TIFF version 6.0
• CALS formats: CALS type 1
• PS/PDF formats: PostScript 3, PDF Version 1.3 (optional)
Relationship between data formats and interfaces
Some data types cannot be processed, based on the interface type. The
relationships between data formats and interface types are shown in the table
below.
Data Formats
CENTRONICS
RS232C TCP/IP VPI
HP-GL formats HP-GL Y Y Y N
HP-GL/2 Y Y Y N
HP-RTL Y N Y N
Versatec
formats
VRF N N Y Y
VCGL N N Y Y
TIFF formats TIFF N N Y N
CALS formats CALS N N Y N
PS/PDF
formats
PostScri
pt
N N Y N
PDF N N Y N
