249
6.5 Printing Using the lp/lpr Command
Message List (6030/6050 only)
This section explains messages that may be displayed during printing using the
lpr command. These messages depend on the system because they are output
from the client workstation.
Status: The lpd daemon on the client failed to create a control file.
Action: Check the spool directory.
Status: The data is too large to store in the spool directory.
Action: Extend the spool directory area or attach the [-s] flag, then execute the lpr
command using a symbolic link.
Status: Cannot start the lpd daemon on the client.
Action: Restart the daemon by the lpr command.
Status: The queue is stopped.
Action: Restart the daemon by the lpr command.
Status: A printer that is not registered in the system was specified.
Action: Check the printer registration in the [/etc/printcap] file.
Status: Failed to delete job No.XX in the print service queue.
Action: Check by the lpq command whether the specified job has already changed
from the wait status in the queue to the processing status.
Cannot create /usr/spool/pltXXX/.seq
Copy file is too large
XXprinter:Jobs queued, but cannot start daemon
XXprinter:Printer queue is disabled
XXprinter:Unknown printer
jobXX can not dequeue
