5.4 Test Printing (6030/6050 only)
5.4
Test Printing (6030/6050 only)
This function prints out a test pattern to verify correct printer operation. The
media size can be selected from A0 through A4.
Procedure
1 Press the < > key with [TEST PLOT]
displayed on the parameter selection
screen.
2 Press the < > key.
3 Select the size of the media to print with the
use of the <
> and < > keys, and then
press the <Set> key.
Press the < > key once it has been set.
4 Press the <Set> key when [SET: to Print.] is
displayed.
The test data will be printed.
Refer to "2.2 Printer Control Panel Usage" for detailed instructions on printer
control panel operation.
MENU
TEST PLOT
TEST PLOT
Plot Size
Plot Size
A0 *
TEST PLOT
SET : to Print.
