Chapter 4 Logical Printer Setup and Operation (6030/6050 only)
2 Click the [Update] button at the upper right corner of the tab to update
the display.
The current status of the machine will display. Use the right scroll bar to
see the remaining details.
Items Displayed on the Status tab
The following items are displayed on the status tab.
IOT Status Details
You may select an interval at which the display will be updated using
the [Update time:] menu at the upper right corner. You also may select
[No auto update] to turn off the feature.
Displayed Item Description
Print service Displays the [Start] and [Stop] buttons used to
start or stop the server.
Job reception Displays the [Start] and [Stop] buttons used to
start or stop job reception.
Print Displays the [Start] and [Stop] buttons used to
start or stop printing.
Printer model Displays the model name of the printer.
Printer status Displays the online/offline status of the printer.
Roll1
Roll2
Roll3(optional)
Roll4 (optional)
Displays the size, type, and amount of media on
each roll. The amount of media is indicated by the
following symbols.
Manual feed Displays [YES] if the optional MSI is installed.
Displays [NONE] if the MSI is not installed.
IOT status Displays the status of the printer.
Refer to [IOT Status Details] in the next table.
Processing data format Displays the data formats that can be processed.
Billing information Displays the following:
• Meter 1: The total area (in square feet or square
meters) of media printed until now
• Meter 2: The total length (in feet and meters) of
media printed until now
• Meter 3: The total number of stamp prints made
until now
