4.3 Logical Printer Print Settings
NO WRAP
Each dot represents the start of the broken line.
Lines printed with the use of the broken line style
shown in the example will be printed as a non-broken
line, as shown in the illustration on the left. This is due
to the fact that the dot appears before the line is
broken, and this constitutes the starting point for
printing another line.
WRAP
Each dot represents the direction in which the broken
line must be printed.
Lines printed with the use of the broken line style
shown in the example will be printed as shown in the
illustration at the left.
Broken line style
Dot
Example
