140
Chapter 4 Logical Printer Setup and Operation (6030/6050 only)
Settings The settings for this function are as follows.
Menu Item Description
Media Size This parameter can be selected from [AUTO], [OTHER], [MIX],
[MIX2], or any of the standard media sizes. The default setting
is [AUTO].
[AUTO] The standard shape priority mode. If the length
of the document exceeds the standard size, the
media is cut to the standard shape that has been
increased in length.
[OTHER] Synchronized cutting is performed on all images.
[MIX] If images that are smaller than the A0 size
exceed the standard size, the media is cut to the
standard size that has been increased in length.
Synchronized cutting is performed on all images
that exceed the A0 size.
[MIX2] If images that are smaller than the A0 size
exceed the standard size, synchronized cutting
is performed on all images.
The selection items for the media size will differ in accordance
with the [Input size] parameter set for the Media series.
• Synchronized cutting is where the media is cut to the non-standard size that
matches the length of the image.
• All printing is carried out on roll media when [OTHER] has been selected.
• Refer to the section on "Media Series" for further details on paper size series.
Menu Item Description
Number of
Fragments
Sets the number of copies to be printed consecutively in a
range from 0 to 99 when [Paper Size] has been specified. The
default setting is [0].
A value that subtracts 1 from the length of the standard size
will be set for [Connect]. For example, in the event of 4A3, 3
will be set for the [Connect].
Lead and
Trail Margins
Specifies whether or not margins will be added. The default
setting is [No].
[NO] No margins will be added.
[ALL] Top and bottom margins will be added to all data.
[LONG] Top and bottom margins will be added to long
images.
Lead Margin Sets the top margin in a range from 0 to 999 mm when the
[Margin] parameter is set to [ALL] or [LONG].
Trail Margin Sets the bottom margin in a range from 0 to 999 mm when the
[Margin] parameter is set to [ALL] or [LONG].
