4.3 Logical Printer Print Settings
in the Y direction.
Descriptions of Area Mode
The area modes are described below.
ADAPTED The data range of the input image is set as the print range
(see Fig.1).
FIXED (HP-GL) The range that encloses the maximum coordinate of the
input image and the coordinates that represent the starting
point of that coordinate is set as the print range.
FIXED (HP-GL/2) The range that encloses the maximum coordinate of the
input image and a starting point of (0,0) is set as the print
range
(see Fig.2).
IP AREA The range specified with the [IP Command] is set as the
print range (see Fig.3).
IW AREA The range specified with the [IW Command] is set as the
print range (see Fig.3).
RASTER The range that corresponds with the input size specified
with the [Destination Raster] command is set as the print
range.
FIRST Only the first quadrant area is set as the print area (see
Fig.4).
Images located in areas outside of the first quadrant area
will not be printed (see Fig.5).
Size
OFFSET
X (–999 to 999) Y (–999 to 999)
A0 0 mm 0 mm
A1 –10 mm 10 mm
A2 20 mm 10 mm
A3 0 mm 0 mm
A4 0 mm 0 mm
