Chapter 4 Logical Printer Setup and Operation (6030/6050 only)
Settings
The settings for this function are as follows.
When [DISABLE] is selected for [Auto Layout], specify the desired offset value
for the media size to be used.
For example, if the following settings have been made, an image with an A2
output size will be printed with an offset of 20 mm in the X direction and 10 mm
The plot area cannot be set up for TIFF and CALS data. Only the auto layout
function can be set for them.
Menu Item Description
Area Mode Sets the range to be printed at [ADAPTED], [FIXED], [IP],
[IW], [RASTER], or [FIRST]. The default setting is
[ADAPTED]. See the next page for more details.
•[IP] and [IW] can be set for HP-GL data only.
•[RASTER] can only be set for HPGL data if the [PS
COMMAND] has been set to [Ignore].
•The PS command takes priority if [Ignore] has not been
set.
Auto Layout Sets up the centering function. The default setting is
[ENABLE].
[ENABLE] Centers the image.
[DISABLE] Does not center the image.
Menu Item Description
Media size
(fixed)
The media size for determining the position of the offset.
The media size displayed will differ in accordance with the
[Output Size] setting in [Media Series].
OFFSET X Sets the amount of offset to the right and left.
The offset value can be set within a range of –999 to 999
mm.
OFFSET Y Sets the amount of offset up and down.
The offset value can be set within a range of –999 to 999
mm.
Refer to the section on "Media Series" for further details on paper groups.
