Chapter 4 Logical Printer Setup and Operation (6030/6050 only)
The settings for this function are as follows.
Example
The media margin settings are determined according to the following for input
data consisting of 300 x 420 mm.
Menu Item Description
X Sets the left and right margin values within a range of –99 to
99 mm.
The default settings is [5 mm].
Y Sets the lead and trail margin values within a range of –99 to 99
mm.
The default settings is [5 mm].
MEDIA MARGIN
Input Judgment
Size
Description
When both X and
Y have been set
to +10 mm
A3: 307 × 430
mm
A2: 430 × 604
mm
Because the input data is smaller than
A3, the A3 size is determined. When
printing is performed on A3 media
(297
× 420), 3 mm of data width will
be cut.
When both X and
Y have been set
to –10 mm
A3: 287 × 410
mm
A2: 410 × 584
mm
Because the input data is larger than
A3, the A2 size is determined. When
printing is performed on A2 paper
(420
× 594), a margin will be located
at the top, bottom, left and right.
