Chapter 4 Logical Printer Setup and Operation (6030/6050 only)
Parameters Unique to Data Formats
[Print Setup]
Menu
Menu Item Description
Data Format
Output
setting
Plot Area Sets the print range, centering, and
offset.
All (see Note)
Color Option Enables or disables the White Mode
(white line) function.
HPGL,
Versatec
TIFF Option Sets up the sorting and output sequence,
and the resolution for the print data.
TIFF
CALS Option Sets up whether or not to disable the
[ROTATE] command.
CALS
PS/PDF Option
Sets the default media size, tray, and
DMS for PS/PDF data.
PS/PDF
Pen setting Define Single
Pen
Defines the attributes of a single pen. HPGL
Define Single
Pen
Defines the attributes of a single pen for
VRF data.
Versatec
Define Multi Pen Defines the attributes of multiple pens.
HPGL
Define Multi Pen Defines the attributes of multiple pens for
VRF data.
Versatec
VCGL Pen Width Sets up the width of the VCGL pen only.
Versatec
VCGL Pen Style Sets up the pen specifications for VCGL
data only.
Versatec
Pen Option
Determines whether or not to change the
pen width when enlarging or reducing.
Versatec, HPGL
Command
setting
Emulation Selects the processing language (HP-GL/
HP-GL2) for the HP-GL data.
HPGL
PS Command Enables and disables the PS command. HPGL
EOP Command Enables and disables the EOP
command.
HPGL
Note
Print ranges cannot be set up for TIFF and CALS.
