4.3 Logical Printer Print Settings
Media setting
(continued)
Media Source Determines whether the paper is to be
fed automatically from a roll or from the
(MSI) Multi Sheet Inserter/Manual Feed
Unit, and sets up the priority ([Job] or
[Controller]).
The optional (MSI) Multi Sheet
Inserter/Manual Feed Unit is
required for manual feeding.
All
Media Type Sets up the media type ([Any], [Bond],
[Vellum], [Film]).
All
User-Defined Size Sets up the user defined size. All
Input setting Input Option Sets up the input size and the number of
fragments.
All
Input Size Margin Sets the top, bottom, left, and right
margin values (from -99 to +99mm).
All
Output setting Priority Sets up the printing priority ([Low],
[Normal], [High]).
All
Title Block Sets up the media size and the title block
location on the print.
All
Split Drawing Sets up the printing parameters for Split
Drawing Mode.
All
Message Option Determines whether messages will be
printed. Selections include [Error
Message], [Label Message], [Date
Message], [Display Position].
All
Printed Copy Sets up the number of copies to be
printed (1 to 99), and the priority ([Job] or
[Controller]).
All
Output Option Sets up the output size. Also sets up
number of fragments and the lead and
trail margins.
All
Size Recognition Determines whether to give priority to
standard shapes or to long shapes when
the standard size is exceeded.
All
Transform Transform Sets automatic enlargement/reduction
(Auto Scale), Mirror Image, and 90-
degree rotation.
All
[Print Setup]
Menu
Menu Item Description Format
