Chapter 3 Printer Setup
Description of the Configuration List Contents
The contents of configuration list are explained below.
Displayed Item Description
H/W CONFIG Model
Product name
Software Version
Installed version of the printer software
RAM Total
Displays the amount of memory installed in the
printer.
Segment Memory
Displays the capacity of the area where spooled print
data is stored during print processing.
Work Memory
Displays the capacity of the area used for running the
controller software.
Frame Memory
Displays the capacity of the image memory (the area
in which images developed into bit maps are stored.)
Harddisk
Displays the model number of the hard disk on which
the input data are spooled.
Option H/W
Additional installed hardware device(s), such as a
folder, stacker, etc.
Finisher Model
Model number of the finisher
S/W CONFIG PostScript
Enabled software option
Network Scan
Disabled software option
Key Install Key
Installation key number for the installed and enabled
software option
PORT SETTING ETHERNET
Ethernet settings
TCP/IP
TCP/IP port settings
SNMP
SNMP status
SYSTEM
PARAMETER
All
The left column lists the available system
parameters.
The center column lists the current system parameter
settings.
The right column lists the possible settings for each
of the system parameters.
