84
Chapter 3 Printer Setup
3.8
System Parameter Setup (Print
Services on Web, 6030/6050)
The system parameters listed below can be set up from Print Services on Web.
These procedures are performed on the Administrator page.
Refer to "3.4 Communication Parameter Setup (Print Services on Web, 6030/6050)"
for information about setting up the [TCP/IP], [Serial], [Centro], [VPI], and [SNMP]
selections in the [System Parameters] menu on the Properties tab.
The parameter nomenclature on Print Services on Web will sometimes differ
from the nomenclature on the printer control panel. The printer control panel
nomenclature appears in bold type in the table below.
Menu Item Description
Priority Determines which of the following should be set up as
the standard for determining the priority sequence of
job output for the same job.
[QIN_FOPEN] Time to start data transfer
[QIN_FCLOSE] Time to end data transfer
Replot Enables or disables the reprinting feature.
Print Density Sets up the default print density level. The density
setting is a numeric value between -99 and 99.
Paper Width for
Special A
(SPA PAPER
WIDTH)
Sets the paper width for SP. JIS/ISO A paper. The
default value is [SP A1].
[SP. A1] 620 or 625mm
[SP. A2] 435 or 440mm
