82
Chapter 3 Printer Setup
3.7
System Settings Setup (Printer Control
Panel, 6050A)
The following system parameters can be set up from the printer control panel.
• Refer to "2.2 Printer Control Panel Usage" for detailed instructions on printer
control panel operations.
Menu Item Description
TCP/IP Allows the entering of an IP Address, IP Subnet Mask
and an IP Gateway address. Also allows DHCP and
RARP/BOOTP to be enabled or disabled.
Date/Time Sets up the internal clock. The parameters are set in
the order year, month, day, hour, and minutes.
Timers This encompasses both low power mode and sleep
mode.
Low power mode sets the time (15-240 minutes) that
must elapse following a print job before the machine
enters low power mode, reducing the temperature of
the fuser and decreasing power consumption.
The default setting is [15] minutes.
The sleep mode sets the time (15-240 minutes) that
must elapse following a print job until the machine
enters the sleep mode; switching off power to the
printer.
The default setting is [55] minutes.
