80
Chapter 3 Printer Setup
6030/6050 Printer Control Panel Example Procedure
1 Press the < > key with [MENU]/[SYSTEM
PARAMETER] displayed.
2 Scroll to the item you wish to set up using
the <
> and < > keys. [Set Date], [AUTO
ROLL], [SPA PAPER WIDTH], [Smoothing],
[Low power mode1], [Low power mode2],
Sleep Mode Sets the sleep mode to [ON] or [OFF] and sets the time
(15 to 120 minutes) that must elapse after the previous
copy or print job until the machine enters the sleep
mode. The sleep mode switches off the power of the
printer.
The default setting is [90] minutes.
Attention Light Not Available
Buzzer Not Available
Print Density Sets up the default print density level. The density
setting is a numeric value between -99 and 99.
Job Recovery Determines how the jobs that were in the print queue
when the printer power was shut off will be processed
when the printer is switched back on. The default
setting is [OFF].
[OFF] Jobs that had not been output when
the power was shut off are canceled
(not printed).
[QUEUED] Prints out only the [Queued] jobs
waiting to be processed.
[ALL] Prints out all jobs that have not been
successfully completed.
• When [ALL] is selected, a ten-page job will be
reprinted from page one when the power is
restored, even if pages 1 to 9 had already printed
before the power was shut off.
• The sequence in which jobs are printed after the
power is restored is based on the ID numbers
that were assigned when each job was received.
Net Cont. Time Not available
Menu Item Description
MENU
SYSTEM PARAMETER
SYSTEM PARAMETER
Job Recovery
