Chapter 3 Printer Setup
3 Select the parameters with the use of the
<
> and < > keys, and then press the
<Set> key.
An asterisk [*] will display on the right side
of the parameters once they have been set.
Centronics (optional) Setup
1 Display [CENTRO] on the setup item
selection screen, and then press the <
>
key.
2 Select the item that is to be set up with the
use of the <
> and < > keys, and then
press the < > key.
[Ack Mode], [DMA Timeout], [EOP
Timeout], and [Job Separation] will display,
in that order.
3 Select the parameters with the use of the
<
> and < > keys, and then press the
<Set> key.
An asterisk [*] will display on the right side
of the parameters once they have been set.
VPI (optional) Setup
1 Display [VPI] on the setup item selection
screen, and then press the <
> key.
2 Select the item that is to be set up with the
use of the <
> and < > keys, and then
press the < > key.
[REPORT OFFLINE], [EOP Timeout], and
[Job Separation] will display, in that order.
Baud Rate
300 *
PORT SETTING
CENTRO
CENTRO
DMA Timeout
DMA Timeout
005 sec *
PORT SETTING
VPI
VPI
Job Separation
